Power Meets Innovation. Redefining Performance.
Welcome to ACE 16XW – The Ultimate Power Tool for Professionals
Introducing the ACE 16XW, the next level in high-performance tools. Engineered for those who demand precision, power, and versatility, the ACE 16XW is designed to handle the most challenging tasks with ease. Whether you're a professional contractor, industrial expert, or a serious DIY enthusiast, the ACE 16XW delivers exceptional results, every time.
| Lifting Capacity | 16 Tonnes (Free on wheels) |
| Engine | ACE-A50 (CEV BS-III), 4-cylinder, water-cooled diesel engine |
| Rated Power | 49.5 HP at 2200 RPM |
| Transmission | Heavy-duty sliding mesh with 6 forward and 2 reverse speeds |
| Clutch | Heavy-duty, single, dry friction cerametallic clutch plate |
| Top Speed | 28 KMPH without load |
| Steering | Lever operated with 55° articulation on either side, 6.5 Mtrs. turning radius |
| Brakes | Air-operated S Cam dual brakes on front wheels, air disc brakes rear |
| Parking Brake | Pneumatically operated fail-safe type |
| Hydraulic System | Gear / Intra Vane type Main Pump, four spool control valve |
| Telescopic Boom | Three-part boom, hydraulically operated extensions |
| Telescoping Time | 18 Sec |
| Boom Luffing Time | 20 Sec |
| Hoist | Winch driven by hydraulic motor, hook block, 50 Mtrs/min speed |
| Rops Cabin | Wide view ROPS cabin for better visibility |
| Fluid Capacities | Engine: 8.00 Ltrs, Fuel Tank: 50.00 Ltrs, Hydraulic Tank: 140.00 Ltrs, Transmission: 48.00 Ltrs |
| Electrical System | 12V, Negative earth, 35 Amp alternator, 88 Amp/hr battery |
| Tyres | Front: 11.00 x 20 (4 Nos), Rear: 14.00 x 25 (2 Nos) |
| Safety | Audio overload indication, Hose failure protection, Safety brakes on hoist |
| Standard Equipment | Fully enclosed ROPS cabin with rotomould canopy |
| Optional Equipment | Simpson 74HP engine, Fly jib: 2.75 Mtrs |
| Operating Weight | 14230 Kgs |
