Unleash the Power of Innovation and Performance
Welcome to Phantom 2WD – Your Ultimate 2-Wheel Drive Solution
Introducing the Phantom 2WD, a state-of-the-art vehicle engineered for those who demand exceptional performance and versatility on and off the road. Designed for both adventure seekers and daily drivers, the Phantom 2WD combines innovative technology with a sleek design to deliver a driving experience like no other.
| A. Overall Length | 6.2 M |
| B. Overall Height | 3.6 M |
| D. Wheel Base | 2.18 M |
| E. Min Ground Clearance | 0.35 M |
| F. Slew Ground Clearance | 0.66 M |
| Width (over bucket) | 2.50 M |
| Track Width Front | 1.84 M |
| Track Width Rear | 1.55 M |
| Max Dig Depth | 4.25 M |
| Reach Ground Level to Rear Wheel Center | 6.73 M |
| Reach Ground Level to Slew Center | 5.50 M |
| Max Working Height | 5.47 M |
| Max Loadover Height | 3.79 M |
| Reach at Ground | 1.77 M |
| Reach at Full Height Bucket Dumped (40°) | 0.89 M |
| Below Ground Level Dig Depth | 0.08 M |
| Dump Height at 40° | 2.76 M |
| Loadover Height | 3.34 M |
| Bucket Pin Height | 3.63 M |
| Max Reach at Full Height | 1.22 M |
| Rollback at Ground | 44° |
| Dump Angle | 45° |
| Loader Breakout Force Arm | 4950 kgf |
| Dipper Tearout Force | 4000 kg |
| Loader Bucket Capacity (Std) | 1.1 cu.m |
| Excavator Bucket Capacity (Std) | 0.24 cu.m |
